Vehicle-Mounted Device Circuit Board

Hongxinda was established by a group of young engineers and sales,is a professional Vehicle-Mounted device circuit board manufacturer. The operational principle of the Vehicle-Mounted device circuit board is fundamentally grounded in electrical theory and the principles of physics. When precise control is necessitated within an electrical system, the circuit board assumes a pivotal role. It typically encompasses a multi-layer printed circuit board structure with numerous intricately designed wires that are configured into specific shapes to facilitate the seamless transfer of electrical signals to or from components.Low price Vehicle-Mounted device circuit board will be offered,welcome your inquire.

Send Inquiry

Product Description

Latest selling Vehicle-Mounted device circuit boards are well accepted by Europe and America, Australia and so on. The primary function of a Vehicle-Mounted device circuit board is to facilitate the operations of a circuit system, providing fixed electrical connection points while effectively mitigating continuity effects. Additionally, it minimizes line length and interference, thereby obviating interference signals and enhancing the noise resistance of the circuit. Furthermore, it significantly streamlines circuit wiring and component layout processes, ultimately reducing design costs. In electronic devices, newest Vehicle-Mounted device circuit boards also serve an aesthetic and protective purpose.


Basic information:

Item name: Vehicle-Mounted device circuit board

Copper Thickness:1OZ,2OZ,3OZ 4OZ 5OZ Customization

Supplier Type:PCB PCBA OEM Factory

Laminate:FR-4,Halogen free,High TG etc

Surface Finishing:OSP, HASL,Immersion gold, Immersion Tin etc

Board thickness:0.3-3.5mm

Solder mask:Green,Black,Blue,Red, white etc

Capacity:up to 50,000㎡/month

Blind & Buried vias:Yes

Inpendence control tolerance:±10%

Testing:100% E-Testing


The working principle of the Vehicle-Mounted device circuit board:

It is to use the board based insulation material to isolate the conductive layer of copper foil on the surface, so that the current flows along the pre-designed route in various components to complete functions such as work, amplification, attenuation, modulation, demodulation, coding and so on.
