3 Layers PCB Board

It is a Cheap 3 Layers PCB Board constructed with three copper conductor layers. The layers of a 3-layer PCB appear to be represented by the conductive foil. Prefer is the insulating layer to bind the various inner layers together for processing in pairs. We are china 3 Layers PCB Board manufacturers.The item insulating substance consequently has at least three layers of conductive material. In this kind of PCB, the ground is shielding support for signals which is the most important term during design. Three-layer PCB Board is practical to align a ground layer with each signal layer due to the potential for high transmission rates in a circuit.

Send Inquiry

Product Description

China 3 Layers PCB Board is a multilayer PCB having 3 copper circuit layers, and the base materials can be FR4, PI (polyimide), PET (polyester), ceramic, etc. 3 Layers PCB Board is rarely used because it is easy to warp during fabrication. 3 Layers PCB Board has an asymmetric PCB structure.


Specification:


Item name: 3 Layers PCB Board

Aspect Ration: Aspect Ration≤13:1

Board thickness: 7mm

MAX Board size: 610*1200mm

Hole copper thick” 25um 1mil

Impedance±10%

MIN Solder mask bridge: 0.10mm

Plugging Vias capability: 0.70mm--1.00mm


3 Layers PCB Board Advantage:


PCB factory directly

PCB Have the comprehensive quality control system

PCB good price

PCB quick turn delivery time from 48hours.

PCB certification(ISO/UL E354810/RoHS)

8 years experience in exporting service

PCB is no MOQ/MOV.

PCB is high quality.Strict through theAOI(Automated Optical Inspection),QA/QC,fly porbe ,Etesting
